| Motor |
Japan YASKAWA 850W servo motor and driver |
| Frame |
Welded Structure |
| Table |
T-slot & vacuum working Table |
| X, Y, Z Guide |
Taiwan PMI 25# Linear Guide, Taiwan TBI Ball Screw |
| Drive type |
Stepper motor |
| X, Y, Z cutting zone (mm) |
1300 x 2500 x 200mm (42’’ x 82’’ x 7.75’’) |
| Maximum speed |
25 000 mm/min (985’’/min) |
| Spindle Power |
2*4.5kw HQD air cooled spindle + HSD 5 + 4 drilling |
| Spindle Speed |
0-18000RPM |
| Repeatability |
+/-.001" |
| CONTROLLER |
SYNTEC
- 4 axes (PLC)
- Dedicated true NC control (G and M codes +)
- G-Code Helical Interpolation
- Supports up to 3kW for axial drive
- Supports both scalar control and field oriented control
- Network connection
- Large solid state onboard memory
- Processor for high speed complex calculations
- Can be customized with our progamming services
|
| SOFTWARES SOLUTION |
WinPCSIGN CNC
- Nesting
- 3D Sculpting in Grayscale
- V-Carving
- Include materials & bits configuration
- Tagential knife support
- Convert images into cutting files
- Import / Export: Eps, Svg, Ai, Dxf, Pdf
|
| COMPATIBLE SOFTWARES |
Vetric, MasterCAM, Fusion 360, AutoCAD ...
|
| Weight |
6615 lbs (3000 kg) |
| POWER REQUIREMENT |
208-230V 3 Phase |
| WARRANTY |
12 Months |
| - Air Blower |
- Private Training |
| - Safety Mats |
- Light Curtains |
| - Camera system allowing cutting with reading of registers (For Print & Cut) |
- Pneumatic positioning system |
| - Mist Coolant Lubrication System for Aluminium Cutting |
- Boring / Drill Head Attachments |
| - Dust Collector Options |
- Dust Collector HorseShoe |
| - Tangential Knife System |
- Tangential Oscillating Knife System |
| - Multi-Tool System (MTS) |
- On-Table 4th Axis /Rotary Indexing Heads |
| - Table Reference Pins (Pop-Up Pins) for Sheet Alignment |
- Becker Vacuum Pump |
| - Vacuum Table with Multiple Zones and Multiple Table Pipes |
- Air Compressor Options |
|
| - Automated Roller Hold Down (Cut 2 sheets at the same time) |
- 45° Degree Knife |
|
- Pneumatic counterbalance system on Z
(Allows greater speed on 3d project) |
- Probe system |
| - Auto Loading System |
- Conveyor system |
| - Automation service |
- Programing service |
| - Evaluation & Optimisation Service for improving your production process |
- Training service accredited by the Ministry of Education |
| - Technician service on the road |
- Parts in inventory |
| - CSA & UL Electrical Certification |
|
