SMX - Blazer (High production system)

Start at 78870.00 ^$USD

SKU: SMXCNCC510RHD

| Brand: SMX CNC

Membership not activated

Not available online

Disponible en magasin

Request quote

Request a demo

Up to 40% in tax credit

Financing Available

DESCRIPTION

Increase your production with the Blazer automated panel processing CNC solutions from SignMAX. Built to the highest standards of quality and performance, each Blazer automated cell combines top-of-the-line CNC machinery with advanced material handling to decrease your cost per part, eliminate unnecessary steps within your workflow process, reduce direct labor, and optimize your machinery usage.

The Blazer CNC Series (Roller Hold Down, Automatic Tool Changer Caroussel System and suction cup system) provide the capability and flexibility of having multiple CNC machines for the cost (and footprint) of one. This machine is at the top of its class, and truly one to be reckoned with for its extremely powerful multi-sheet, nested-base, auto-loading and cutting multiple stacked sheets capabilities.

The Blazer Series CNC router is our ultimate workhorse and we continue to add the options and improvements to keep our customers outperforming the competition!

1- CNC (4' x 10' - ATC) with Automatic Tools Changing System

1 - Automatic Loading Platform

1 - Conveyor

1 - Caroussel with 8-tools

1 - Suction cup System

1 - HSD Spindle - 12 HP

Financing available
	Financing available

Motor	Japan YASKAWA 850W servo motor and driver
Frame	Welded Structure
Table	T-slot & vacuum working Table
X, Y, Z Guide	Taiwan PMI 25# Linear Guide, Taiwan TBI Ball Screw
Drive type	Stepper motor
X, Y, Z cutting zone (mm)	1300 x 2500 x 200mm (42’’ x 82’’ x 7.75’’)
Rapid speed	1765 ipm (45 000 mm/min)
Spindle Power	2*4.5kw HQD air cooled spindle + HSD 5 + 4 drilling
Spindle Speed	0-18000RPM
Repeatability	+/-.001"
CONTROLLER	SYNTEC 4 axes (PLC) Dedicated true NC control (G and M codes +) G-Code Helical Interpolation Supports up to 3kW for axial drive Supports both scalar control and field oriented control Network connection Large solid state onboard memory Processor for high speed complex calculations Can be customized with our progamming services
SOFTWARES SOLUTION	WinPCSIGN CNC Nesting 3D Sculpting in Grayscale V-Carving Include materials & bits configuration Tagential knife support Convert images into cutting files Import / Export: Eps, Svg, Ai, Dxf, Pdf
COMPATIBLE SOFTWARES	Vetric, MasterCAM, Fusion 360, AutoCAD ...
Weight	6615 lbs (3000 kg)
POWER REQUIREMENT	208-230V 3 Phase
WARRANTY	2 years

FEATURES

8-TOOLS AUTOMATIC TOOLCHANGING CAROUSSEL

This Automatic Tool Changer is near the spindle to drastically reduces the time needed to change you CNC tools.

By automatically changing cutting bits between cuts, it's eliminate the need for the CNC operator to change and calibrate tools by hand. A option that make BLAZER CNC a great time saving investment.

8-Tools Automatic Toolchanging Caroussel

SYNTEC CONTROLLER

This powerful control system integrates all the components of the CNC system, such as digital controllers, programmable controllers and man-machine interfaces.

This is the reasons why our Ingineering and programing team are able to develop automated control and processes to add more options and optimize the BLAZER production capabilities.

STEEL HARDENED GANTRY WITH 12' Z CLEARANCE

BLAZER CNC Series has an 12' Z Clearance Steel Hardened Gantry. Which makes this CNC one of the best machine to cut threws that thick cut and stacks in no time!

FULLY CUSTOMIZABLE - MORE THAN 1500 CONFIGURATIONS!

The BLAZER CNC Series offer many options and automation process that allow us to create the perfect machine for your current production needs.

Ours Technicians, Programming and Engineering Team are able to modify and improve this machine, even years after his purchase, to fit your ever productions needs as your business growth.

12 HP HSD AIR-COOLED MOTOR SPINDLE

HSD air-cooled motor spindle offer extremely high reliability, are wide range of powers and operating speeds.

It can deliver up to 2400 RPM and it's fully compatible with automatic carousell tools changing system.

OPTIONS

- Air Blower	- Private Training
- Safety Mats	- Light Curtains
- Camera system allowing cutting with reading of registers (For Print & Cut)	- Pneumatic positioning system
- Mist Coolant Lubrication System for Aluminium Cutting	- Boring / Drill Head Attachments
- Dust Collector Options	- Dust Collector HorseShoe
- Tangential Knife System	- Tangential Oscillating Knife System
- Multi-Tool System (MTS)	- On-Table 4th Axis /Rotary Indexing Heads
- Table Reference Pins (Pop-Up Pins) for Sheet Alignment	- Becker Vacuum Pump
- Vacuum Table with Multiple Zones and Multiple Table Pipes	- Air Compressor Options
- Automated Roller Hold Down (Cut 2 sheets at the same time)	- 45° Degree Knife
- Pneumatic counterbalance system on Z (Allows greater speed on 3d project)	- Probe system
- Auto Loading System	- Conveyor system
- Automation service	- Programing service
- Evaluation & Optimisation Service for improving your production process	- Training service accredited by the Ministry of Education
- Technician service on the road	- Parts in inventory
- CSA & UL Electrical Certification

MATERIALS

Any Type Of Wood

High-Density Foam

Plastics

Non-Ferrous Metals*

(Cooling System Needed)

Training

With every purchase of CNC we included 5 hours of free training to show you how to use the router & the software.

Software

WinPCSIGN CNC include all the tools you need to design & create your projects. No need to be a machinist WinPCSIGN CNC is easy to learn and easy to use.

Ready to be certified

All our CNC systems are designed & made with Canadian & American industrial standard in mind and are ready for CSA & UL certification.

2 Years Warranty

Our warranty covers parts and all determined necessary labor to keep your machine functioning as it should.

Support

We provide support via phone, email, or internet connectivity. In most cases, we are able to diagnose problems remotely so you can get your machine running again.

Design in Canada

We believe in and stand by our machines because, unlike the competition, we really design and engineer them!

TRAINING & SUPPORT

SignMAX includes 1 day training with all SMX CNC Routers. We have all the parts in our inventory and our certified technicians are there to help you by phone, email, PC-to-PC connectivity and at your enterprise.
